Matte Black Aluminum Foil Tape AFA2565B

Matte black aluminum foil tape is a matte-black lacquered non-reflective aluminum foil tape. 25 micron (1.0mil) matte black aluminum foil, combined with a high performance solvent acrylic adhesive, protected by an easy-release silicone release paper.

Matte black aluminum foil tape use for taping exposed edges and board joints of HVAC ductwork system. Also used to block lighting spills on heat generating equipment. Matte black finish does not reflect light.

  • Matte Black Aluminum Foil Tape Introduction

AF-Alum. Foil backing

A-Acrylic adhesive

25-Backing thickness25um

65-Tape thickness 65um

B-Black Lacquered backing surface



AFA Series HVAC aluminum foil tapes are single-faced adhesive tape of Aluminum Foil backing which is coated by Solvent Acrylic adhesive (PSA). Black Aluminum Foil Tape is industrially manufactured, and thus can be manipulated based on the selection of the monomers used in the formulation.


Matte Black Aluminum Foil Tape will be offer good tack and adhesion to width range of temperature (from -30 degrees to 150 degrees ).


Black Aluminum Foil Tape will be good aging stability, high resistance to UV, ozone and humidity, best useful in long-term, outdoor applications.



FEATURES

Matte black aluminum foil, match the Black FSK Faced Ductwork and Pipe insulation.

Matte black finish does not reflect light.

Good aging resistance both indoors and outdoors.

Low moisture vapor transmission rate offers excellent sealing and patching performance.



TYPICAL PHYSICAL PROPERTIES

PROPERTIES

METRIC

ENGLISH

TEST METHOD

Black coating

2.5 Micron

0.1Mil

PSTC-133 / ASTM D 3652

Backing Thickness

25 Micron

1.0Mil

PSTC-133 / ASTM D 3652

Total Thickness

62.5Micron

2.5Mil

PSTC-133 / ASTM D 3652

Adhesion to Steel

15N/25mm

54Oz./In.

PSTC-101 / ASTM D 3330

Tack Rolling ball

20cm

8.0In

PSTC-6 / ASTM D 3121

Tensile Strength

40 N/25mm

9.1Lb/In

PSTC-131 / ASTM D 3759

Elongation

3.0%

3.0%

PSTC-131 / ASTM D 3759

Service Temperature

-30℃ to +120℃

-22℉ to +248℉



Applying Temperature

-10℃ to +40℃

+50℉ to +105℉





TYPICAL APPLICATIONS:

It is primarily used in the entertainment industry for blocking and suppressing spills and leakages on heat generating equipment such as projectors, light cans, barndoors, and similar equipment. Lighting decorators / engineers can use it to create shadows, form barn doors and adapt gobos. Used in situations where extreme heat might otherwise burn flags or cutters,. Also used in the construction industry for joining elastomeric insulation systems.



ROLL SIZE:

Finish Roll:

50mm x 50m     2” x 55yds

75mm x 50m     3” x 55yds

Log Roll:   1020mm x 50m

Jumbo Roll: 1020mm x 3000m
